GR5 Series
Energy-saving and Maintenance Advantages of GR Series Steel Wire Rope Vibration Isolators
Xi'an Hoan Microwave's GR series steel wire rope vibration isolators have significant advantages in terms of energy conservation and maintenance costs. Thanks to their unique metal wire structure, they do not require regular replacement like rubber vibration isolators, which greatly reduces the maintenance costs throughout the equipment's entire life cycle. Measured data shows that the related maintenance costs of equipment using GR series vibration isolators are reduced by more than 40% compared with traditional solutions.
In terms of energy saving, the GR series reduces energy loss by effectively isolating equipment vibration. Taking a certain type of industrial pump as an example, after installing the GR5 Series vibration isolator, the energy loss caused by vibration is reduced by about 15%, and the annual electricity cost savings can reach several thousand yuan. In addition, the GR series can also extend the service life of equipment. Customer feedback shows that the mean time between failures (MTBF) of equipment with GR vibration isolation is extended by 30%-50%.
The GR series products provided by Xi'an Hoan Microwave adopt a modular design, supporting quick replacement, which greatly shortens the equipment downtime. The company has also developed an intelligent monitoring system that can monitor the status of vibration isolators in real-time and predict the remaining service life, helping customers achieve preventive maintenance. This innovative service model has been successfully applied in many key engineering projects.
Dimension Parameter Table
| Model | Height±1.5 (mm) | Width (mm) | Weight (kg) | Mounting Options | Thru Hole(mm) | Thread (mm) | C‘sink(°) |
| GR5-80A-A | 41 | 48 | 0.72 | A,B,C,D,E,S | ∅7 | M6*1.0 | 90 |
| GR5-38A-A | 53 | 54 | 0.77 |
| GR5-27A-A | 60 | 59 | 0.81 |
| GR5-16A-A | 76 | 67 | 0.9 |
Static-Load Curve
| No. | Model | Max Static Load (N) | Max Deflection (mm) | Kv(Vibration) (KN/m) | Ks(Shock) (KN/m) |
| 1 | GR5-80A-A | 80 | 19.6 | 22 | 11 |
| 2 | GR5-38A-A | 38 | 28.7 | 11 | 4.4 |
| 3 | GR5-27A-A | 27 | 34.8 | 7.9 | 3.2 |
| 4 | GR5-16A-A | 16 | 49.3 | 4.4 | 1.4 |
| No. | Model | Max Static Load (N) | Max Deflection (mm) | Kv(Vibration) (KN/m) | Ks(Shock) (KN/m) |
| 1 | GR5-80A-A | 24 | 18.3 | 12 | 6.1 |
| 2 | GR5-38A-A | 13 | 28.4 | 5.3 | 2.3 |
| 3 | GR5-27A-A | 11 | 36.1 | 3.6 | 1.4 |
| 4 | GR5-16A-A | 6.7 | 53.8 | 1.9 | 0.7 |
| No. | Model | Max Static Load (N) | Max Deflection (mm) | Kv(Vibration) (KN/m) | Ks(Shock) (KN/m) |
| 1 | GR5-80A-A | 20 | 16.5 | 4.4 | 4.4 |
| 2 | GR5-38A-A | 13 | 25.7 | 2.1 | 2.1 |
| 3 | GR5-27A-A | 11 | 32.5 | 1.4 | 1.4 |
| 4 | GR5-16A-A | 6.7 | 48.5 | 0.7 | 0.7 |
FAQ
1.Q:Are you a manufacturer or a trading company?
A: We are a manufacturer, not a trading company. We produce our products in our own facilities, ensuring full control over the quality and production process. This allows us to offer competitive pricing and customized solutions directly to our clients.
2.Q:Can you customize products for us?
A:Yes, we have the capability to customize our products to meet your specific needs. Please contact us with your requirements, and our team will work with you to create a tailored solution that fits your preferences.
3.Q:What is the lead time?
A:Sample will usually take 2 to 5 days. For the mass production, it will estimated take 7 to 20 day, Faster delivery when our
factory has stock.
4.Q:Can I get some samples before place order and how long for a sample?
A:Yes, sample order is accepted
5.Q:How is your shipping?
A:1)worldwide shipping service available
2)please contact before order as shipping cost varies time to time.
6.Q:Do you offer discounts for bulk orders?
A:Yes, we offer discounts for bulk orders. The discount percentage may vary depending on the order quantity.
