JMZ-1-3.5A Adjustable Vibration Isolator for HVAC Equipment, 3.5kg Load

  • 1
  • 2
  • 3

Warranty : 1 year

Application : HVAC Equipment

Condition : New

Certifications : UL Listed, RoHS Compliant

Machinery Test Report : Not Available

Type : Vibration Isolator

Adjustability : Adjustable

Dimensions : Various sizes available

Marketing Type : New Product 2025

Model : JMZ-1-3.5A

Installation Method : Bolted

Brand Name : Hoan

Model Number : JMZ-1-3.5A

Place of Origin : China

MOQ : 4

Payment Terms : L/C,D/A,T/T,,D/P,MoneyGram

Temperature Range : -40°F to 180°F

Showroom Location : None

Mounting Type : Top Plate

Contact Now

JMZ-1-3.5A Friction Damping Vibration Isolator for Precision Equipment
JMZ Series: Addressing Environmental Ache Points in Precision Manufacturing

In precision machining, optical inspection, semiconductor manufacturing, and microscale scientific research, environmental micro-vibrations can significantly impair equipment precision and product yield rates. The JMZ Friction Damping Vibration Isolator from Xi'an Hoan Microwave Co., Ltd. provides an effective solution for these critical industry challenges.

With highly efficient damping characteristics, the JMZ isolator significantly attenuates broadband vibrations from floor transmission, nearby traffic, or internal mechanical equipment—particularly challenging mid-to-low frequency disturbances. Placing precision instruments on the JMZ vibration isolation platform creates a "dynamic stability zone" that suppresses platform resonance and ensures accuracy and repeatability in machining, measurement, and observation processes.

Dimension Parameters
JMZ-1-3.5A Adjustable Vibration Isolator for HVAC Equipment, 3.5kg Load
Model Nominal Load (kg) B A±0.2 H h±0.5 T d d1 D
JMZ-1-1.0A 1.0 44 35 50 36 SW14 M5-7H 5.1～5.4 39.5
JMZ-1-1.5A 1.5 Same as JMZ-1-1.0A except nominal load
JMZ-1-2.0A 2.0 Same as JMZ-1-1.0A except nominal load
JMZ-1-3.0A 3.0 Same as JMZ-1-1.0A except nominal load
JMZ-1-3.5A 3.5 Same as JMZ-1-1.0A except nominal load
Performance Characteristics
JMZ-1-3.5A Adjustable Vibration Isolator for HVAC Equipment, 3.5kg Load JMZ-1-3.5A Adjustable Vibration Isolator for HVAC Equipment, 3.5kg Load
Model Pz Nominal Load (KG) Pz Max Deflection (mm) Vibration (Kv) Shock (Ks) Resonant Frequency (Hz) Working Temperature(℃)
JMZ-1-1.0A 1.0 3±1.5 ≤3.5 30g/11ms ＜15 -65～+120
JMZ-1-1.5A 1.5 Same as JMZ-1-1.0A except nominal load
JMZ-1-2.0A 2.0 2±1.5 Same as JMZ-1-1.0A except noted parameters
JMZ-1-3.0A 3.0 3±1.5 Same as JMZ-1-1.0A except noted parameters
JMZ-1-3.5A 3.5 Same as JMZ-1-1.0A except nominal load
Unique Characteristics
  • No creep or ageing
  • High internal damping
  • Very wide temperature range (-65℃ to +120℃)
  • Wide variety of possible fittings
  • Rapid and economical prototyping
  • Extremely rugged construction and long lifespan
  • Excellent combined shock and vibration isolation
  • Resistant to chemical agents, seawater, ozone, and UV rays
Application Examples
JMZ-1-3.5A Adjustable Vibration Isolator for HVAC Equipment, 3.5kg Load
